SBR/Styrene-Butadiene Rubber Sheeting

SBR synthesised from raw materials derived from oil. Above half of the synthetic rubber produced in the world is SBR.

INQUIRY

Description

SBR/Styrene-Butadiene Rubber Sheeting made from Styrene and Butadiene copolymer (the SBR synthesised from raw materials derived from oil). Above half of the synthetic rubber produced in the world is SBR.

CHEMICAL RESISTANCE of SBR

Good resistance to inorganic chemical products, not so to oxidizing acids.
Limited resistance to mineral acids, and unsuitable for organic liquids in general.

PROPERTIES of SBR

It can attain higher abrasion resistance than NR.
Similar to NR, but with better ageing and temperature resistance.
Moderate tearing, ozone and weather resistance.

Product Dimensions

Thickness	Width	Length
1mm~40mm	1000mm~2000mm	5m~20m

We can supply sheet cut in strips, in different widths, according to your requirements.

Normal colours, hardness and technical specifications we offered

Ref	Material	Colours	Specific Gravity (g/cm³)	Hardness (Shore A)	Tensile Strength (Mpa)	Elongation (%)
PREMSBR1001B	SBR	Black	1.50±0.05	60±5	3.0~3.5	200
PREMSBR1001B	SBR	Black	1.40±0.05	70±5	4.5~5.0	250~300
PREMSBR1001B	SBR	Black	1.50±0.05	80±5	3.5~4.0	250
PREMSBR1001B	SBR	Black	1.50±0.05	90±5	3.5~4.0	250

OTHER COLOURS, HARDNESS AND TECHNICAL SPECIFICATIONS CAN BE AVAILABLE UPON REQUEST

Working Temperature range: -50°C to +110°C
