Silicone Round Cord

Round cords and round cord rings achieve their static sealing effect from the deformation of the cross section after installation and compression into the installation space.
Description
Round cords and round cord rings achieve their static sealing effect from the deformation of the cross section after installation and compression into the installation space. A round cord ring is similar to an O-ring. Round cord rings are often used for repairs and assembled to size on site.


Meridian offers round cords and round cord rings made of the materials VMQ/Silicone commonly.



Other material and cross section can be available upon customers’ request.

ADVANTAGES AT A GLANCE
*Media pressure strengthens the sealing function in the opera¬tional state
*Round cords can be individually joined into round cord rings in the desired dimensions at the point of use
*In the case of round cord rings: a high degree of flexibility thanks to customized dimensions



TOLERANCES

Accordance with ISO 3302-1 E3



DIMENSIONS

The currently available dimensions


ITEM Inch Metric Length Material
CORDSI/1X30/70RR 0.04 1 mm 30 m Silicone 60
CORDSI/2X30/70RR 0.079 2 mm 30 m Silicone 60
CORDSI/3X30/70RR 0.118 3 mm 30 m Silicone 60
CORDSIIN/125X30/70RR 0.125   30 m Silicone 60
CORDSI/4X30/70RR 0.157 4 mm 30 m Silicone 60
CORDSI/5X30/70RR 0.196 5 mm 30 m Silicone 60
CORDSI/6X30/70RR 0.236 6 mm 10 m Silicone 60
CORDSIIN/250X10/70RR 0.25   10 m Silicone 60
CORDSI/7X10/70RR 0.275 7 mm 10 m Silicone 60
CORDSI/8X10/70RR 0.313 8 mm 10 m Silicone 60
CORDSI/9X10/70RR 0.354 9 mm 10 m Silicone 60
CORDSI/10X10/70RR 0.394 10 mm 10 m Silicone 60
CORDSI/12X10/70RR 0.472 12 mm 10 m Silicone 60
CORDSIIN/500X10/70RR 0.5   10 m Silicone 60
CORDSI/14X10/70RR 0.55 14 mm 10 m Silicone 60
CORDSI/15X10/70RR 0.59 15 mm 10 m Silicone 60
CORDSI/18X10/70RR 0.708 18 mm 10 m Silicone 60
CORDSIIN/750X10/70RR 0.75   10 m Silicone 60
CORDSI/20X10/70RR 0.788 20 mm 10 m Silicone 60
