NBR/NITRILE Rubber Sheeting

Depending on the acrylonitrile content (ACN) NBR can be classified as: Low ACN (18-24%). Medium ACN (34%) and High ACN (50%) content.
Description
NBR/NITRILE Rubber Sheeting
Copolymers of butadiene and acrylonitrile, usually known as NITRILE RUBBERS

Depending on the acrylonitrile content (ACN) NBR can be classified as: Low ACN (18-24%). Medium ACN (34%) and High ACN (50%) content.

With increasing the ACN content of NBR, resistance to oils, fuel, etc. be increased, tensile strength, resistance to abrasion, hardness, temperature resistance and permeability be improved.

CHEMICAL RESISTANCE of NBR
  • Good resistance to most inorganic chemical products, apart from antioxidizing agents and chlorides.
  • Satisfactory resistance to aliphatic hydrocarbons, but limited resistance to aromatics.

PROPERTIES of NBR
  • Resistance to oils, and can be formulated for applications at relatively high temperatures.
  • Good mechanical properties, such as traction, compression and flexion.
  • Impermeable to gases.

Product Dimensions
Thickness Width Length
1mm~40mm 1000mm~2000mm 5m~20m

We can supply sheet cut in strips, in different widths, according to your requirements.

Normal colours, hardness and technical specifications we offered
Ref Colours Specific
Gravity
(g/cm3)
Hardness
(Shore A)
Tensile
Strength
(Mpa)
Elongation
(%)
PREMNBR3001B Black 1.45±0.05 60±5 5 300
PREMNBR3001B Black 1.45±0.05 70±5 8 150
PREMNBR3001W White 1.45±0.05 60±5 5 300
PREMNBR3001W White 1.45±0.05 70±5 8 150

OTHER COLOURS, HARDNESS AND TECHNICAL SPECIFICATIONS CAN BE AVAILABLE UPON REQUEST
Working Temperature range: -30°C to +100°C
